347H SS Sheet, ASTM A240 TP347H Stainless Steel Sheets, SS 347H Sheets, UNS S34709 Sheet, 347H Stainless Steel Hot Rolled Sheets, SS 347H Sheets Stockist, Stainless Steel 347H Sheets, 347H Stainless Steel Sheet, 1.4961 Sheets, Stainless Steel 347H Sheets Supplier in Mumbai, India.
Palgotta Steel Pvt Ltd suppliers of Stainless Steel 347H Sheet, a superior stainless steel sheet, to meet the most demanding industrial requirements. This sheet offers exceptional corrosion resistance and durability compared to stainless steel sheets. Its excellent weldability and formability make it suitable for various fabrication processes such as bending, flanging, and welding. Its low carbon content is magnetically soft, enhancing corrosion resistance in high-temperature environments.
347H Stainless Steel Sheet is heat-treatable and non-magnetic in the annealed condition. This molybdenum-bearing stainless steel grade provides excellent corrosion resistance, strength, and high-temperature performance. It is ideal for industrial applications such as heat exchangers, pressure vessels, and automotive exhaust systems. It can operate up to 870°C (1600°F) without affecting its mechanical properties.
347H Stainless Steel Sheet Suppliers, SS 347H CR Sheets, 347H SS Sheet Metal, Jindal Stainless Steel Sheet 347H Price List, Stainless Steel 347H Perforated Sheets, Stainless Steel 347H Sheet Manufacturers, ASME SA240 TP347H SS Sheet, SS 347H Shim Sheets, Stainless Steel 347H Sheets Stockist in India.
Contact us today to learn more about our high-quality Stainless Steel 347H Sheets and how they can benefit your industrial applications.
What is a 347h stainless steel sheet?
A 347H stainless steel sheet is a molybdenum-bearing austenitic stainless steel grade with excellent resistance to corrosion and high-temperature environments. Its low carbon content makes it magnetically soft and enhances its corrosion resistance in high-temperature environments. This sheet offers excellent weldability and formability, making it ideal for fabrication processes like bending, flanging, and welding. It is commonly used in industries like chemical, petrochemical, and food that require high-temperature and corrosion resistance.
What fabrication processes are suitable for Stainless Steel 347H Sheets?
Stainless Steel 347H Sheets are versatile in fabrication and can be readily welded, bent, flanged, and formed. They can also be machined and fabricated using standard techniques such as cutting and drilling. It is recommended to use tools specifically designed for stainless steel to avoid contamination or damage to the material.
Can Stainless Steel 347H Sheets be welded and formed easily?
Stainless Steel 347H Sheets can be readily welded, bent, flanged, and developed due to their excellent weldability and formability properties. They can also be machined and fabricated using standard techniques such as cutting and drilling.
What is the maximum temperature that Stainless Steel 347H Sheets can withstand?
Stainless Steel 347H Sheets can withstand high temperatures up to 870°C (1600°F) without losing their mechanical properties, making them suitable for high-temperature applications such as heat exchangers, pressure vessels, and automotive exhaust systems.
Stainless Steel 347H Sheet Grades and Specification
- Sheet Standards: ASTM A240 / ASME SA240
- Sheet Dimensions: ASTM, ASME, and API
- Material: Stainless Steel
- Sheets Width: 160 – 1.500,00 mm
- Sheets Thickness: 0.2 – 6.0 mm
- Sheets Length: 100 to 6.000,00 mm
- Sheets Tolerance: acc. EN ISO 9445:2006 other on request
- Surface finishes: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, perforated, embossed, hairline, sand blast, Brush, etching, Hot rolled Sheet (HR), Cold rolled Sheet (CR), SATIN (Met with Plastic Coated) etc
- Hardness: Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
- Types: Sheets, Perforated Sheet
Equivalent Material of Stainless Steel 347H Sheets
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN |
| SS 347H | 1.4961 | S34709 | SUS 347H | – | X6CrNiNb18-12 |
Specialized in Stainless Steel 347H Sheets
- Stainless Steel UNS S34709 Sheets
- ASTM A240 TP347H SS Sheets
- Cut To Size Stainless Steel 347H Sheet
- 347H Stainless Steel Sheets Stockist In Mumbai
- SUS 347H Sheets
- 347H SS Both Side Polished Sheet
- Stainless Steel 347H Sheets Supplier in India
- ASME SA240 TP347H Stainless Steel Sheets
- Stainless 347H Sheets Wholesale in Mumbai
- Stainless Steel 347H Sheets Exporters
- #8 Mirror Polish Finish Stainless Steel 347H Sheets
- Stainless Steel 347H Cold Rolled Sheets
- Stainless Steel 1.4961 Sheets
- Stainless Steel 347H Sheets Supplier in India
- Stainless Steel 347H Sheets Stockholder
- Stainless Steel 347H Perforated Sheets
- AISI 347H Sheets
- 347H SS #4 Polish Finish Sheets
- SS 347H 2D Finish Sheets Supplier
- SS 347H Sheets at Best Price List In India
- Stainless Steel 347H Shim Sheets
- SS 347H 2B Finish Sheets in Mumbai
- Stainless Steel 347H Sheets Stocks
- 347H Stainless Steel Hot Rolled Sheets
- 347H Stainless Steel Sheets Manufacturer
- Stainless Steel 347H BA Finish Sheet in India
- Austenitic Stainless Steel 347H Sheets
- Stainless Steel 347H Industrial Sheets
Chemical Properties Of 347H Stainless Steel Sheet
| Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
| SS 347H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 8xC – 1.10 | 9.0 -13.0 | 63.72 min |
SS 347H Sheets Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
ASME SA240 Stainless Steel 347H Sheet Sizes
| SS 347H Sheet Weight per Unit Area | Estimated Weight per Sheet |
|---|---|
| 0.630 lbs/ft²3.07566 kg/m² | 15.12 lbs6.84936 kg |
| 0.630 lbs/ft²3.07566 kg/m² | 18.90 lbs8.5617 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 18.15 lbs8.22195 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 22.68 lbs10.27404 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 24.19 lbs10.95807 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 30.24 lbs13.69872 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 20.16 lbs9.13248 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 25.20 lbs11.4156 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 24.19 lbs10.95807 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 30.24 lbs13.69872 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 36.29 lbs16.43937 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 32.26 lbs14.61378 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 40.32 lbs18.26496 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 48.39 lbs21.92067 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 25.20 lbs11.4156 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 31.50 lbs14.2695 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 30.24 lbs13.69872 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 37.80 lbs17.1234 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 45.37 lbs20.55261 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 40.32 lbs18.26496 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 50.41 lbs22.83573 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 60.49 lbs27.40197 kg |
| 1.512 lbs/ft²7.381584 kg/m² | 30.24 lbs13.69872 kg |
| 1.512 lbs/ft²7.381584 kg/m² | 37.80 lbs17.1234 kg |
| 1.512 lbs/ft²7.381584 kg/m² | 36.29 lbs16.43937 kg |
347H Stainless Steel Sheet Thickness & Weight
| Thickness | Thickness | Size Chart | SS 347H Sheet Unit weight | SS 347H Sheet Approx Weight | ||
|---|---|---|---|---|---|---|
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
Stainless Steel 347H Sheet Dimensions
| Surface finish | Thickness (mm) | Width (max mm) |
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | 1524 |
| 2H – Work hardened | 0.4–6.35 | 1524 |
| Polished, brushed | 0.5–4.0 | 1524 |
| Surface finish | Gauge (in) | Width (max in) |
| 2B – Cold rolled, heat treated, pickled, skin passed | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled | 12–24 | 60 |
| Polished (not brushed) | 11–24 | 60 |
Polished and Plain 347H Stainless Steel Sheet
huge stock of polished ss 347H sheets, finishes include Natural, Bright, Brushed, Dull Polished, Mirror and Embossed Rigidised
| PRODUCT | FINISH | THICKNESS MM | MAX SHEET SIZE MM |
|---|---|---|---|
| Grade 347H | Plain 2B | 0.9 | 2000 x 1000 |
| Bright | 0.9 | 2000 x 1000 | |
| Brushed Finish | 0.9, 1.2 | 2000 x 1000, 2500 x 1250 | |
| Rimex Super Mirror | 0.8, 1.2 | 2400 x 1200, 2500 x 1250 | |
| Embossed | 0.8, 1.0 | 2500 x 1250 |
Perforated Stainless Steel Sheet 347H
We now offer circle cutting in Stainless Steel Grade 347H perforated sheets up to 1000mm diameter.
| Hole Dia mm | Hole Centres mm | O/A | Finish | Tck mm | Full Sheet Size mm |
|---|---|---|---|---|---|
| 0.75 | 1.5 | 23% | 2B | 0.6 | 2000 x 1000 |
| 1 | 2 | 23% | 2B | 1.0 | 2000 x 1000 |
| 1.5 | 2.6 | 30% | 2B | 1.0 | 2000 x 1000 |
| 2 | 3.5 | 30% | 2B | 1.0 | 2000 x 1000 |
| 2 | 3.5 | 30% | 2B | 1.0 | 2000 x 1000 |
| 3 | 5 | 33% | 2B | 1.0 | 2000 x 1000 |
| 4 | 5.6 | 46% | 2B | 1.0 | 2000 x 1000 |
| 5 | 8 | 35% | 2B | 1.0 | 2000 x 1000 |
| 6 | 8 | 51% | 2B | 1.0 | 2000 x 1000 |
| 8 | 10 | 58% | 2B | 1,0 | 2000 x 1000 |
347H Stainless Steel Sheet Price List
- cheap price no.1 2b surface stainless steel sheet 347h
us $500-1800 / ton - grade 347h hot rolled and cold rolled steel sheet
us $600-2900 / ton - the most popular stainless steel sheet 347h / sus 347h 2b manufacturer
us $100-1500 / ton - no.1 2b sheet and 2b finish 347h stainless steel Sheet price
us $13-50 / piece - cold rolled / hot rolled 347h stainless steel sheet
us $350-1760 / ton - 347h 2b finish stainless steel sheet price
us $987-2000 / ton - top quality 347h stainless steel sheet with factory price
us $1000-2000 / ton - 347h 2b surface stainless steel metal sheet
us $1000-2200 / ton - mirror / polish / brush finished 347h stainless steel sheet
us $300-1850 / ton - a240 tp347h stainless steel sheet – no.8 mirror polish
us $115-1250 / ton
