UNS S31703 Sheet, 317L Stainless Steel Sheet, 1.4438 Sheets, 317L Sheet, SS 317L Sheets Stockist, 317L Stainless Steel Hot Rolled Sheets, 317L SS Sheet, ASTM A240 TP317L Stainless Steel Sheets, Stainless Steel 317L Sheets, Stainless Steel 317L Sheets Supplier in Mumbai, India.
Palgotta Steel Pvt Ltd offers SS 317L Sheets that are perfect for applications requiring exceptional corrosion resistance, strength, and ease of fabrication. Our sheets can be quickly hot or cold-worked, making them suitable for various fabrication processes. Our SS 317L sheets contain high molybdenum content, providing superior general corrosion and pitting resistance compared to other stainless steel grades.
Also, our sheets offer outstanding crevice corrosion and stress-cracking resistance in chloride-containing media, including seawater and salt solutions. They also exhibit excellent mechanical properties at both high and low temperatures.
Contact us today to learn more about our Stainless Steel 317L Sheet Price and Other Specifications and services.
ASME SA240 TP317L SS Sheet, Stainless Steel 317L Sheet Manufacturers, 317L Stainless Steel Sheet Metal, SS 317L Shim Sheets, 317L Stainless Steel Sheet Suppliers, SS 317L CR Sheets, Jindal Stainless Steel Sheet 317L Price List, 317L SS Perforated Sheets, Stainless Steel 317L Sheets Stockist in India.
What is Stainless Steel 317L Sheet?
The low-carbon variant of SS 317 stainless steel, known as Stainless Steel 317L Sheet, provides exceptional corrosion resistance and high-temperature strength compared to other stainless steel grades. Its superior formability, weldability, and machinability make it an excellent option for applications requiring outstanding mechanical properties and corrosion resistance.
What are the features of the SS 317L Sheet?
Features of SS 317L Sheet include good oxidation resistance in intermittent service to 1600F (871C), excellent uniformity of colour when annealed after fabrication, low thermally induced stress relaxation compared to other austenitic alloys, good flexibility, superior long-term creep strength, and ease of welding and forming.
What are the advantages of the SS 317L Sheet?
Advantages of SS 317L Sheet include excellent corrosion resistance to a wide range of organic, inorganic, and industrial acids, low annealed hardness, superior strength at high temperatures, and good weldability and formability suitable for a variety of applications.
What are the applications of Stainless Steel 317L sheets?
Applications of SS 317L Sheet include automotive components, marine equipment, oil and gas processing equipment such as exchangers and heaters, chemical processing equipment including pumps and valves, and food industry containers consisting of vats and tanks due to their excellent corrosion-resistant properties. Furthermore, this alloy applies to kitchen appliances like sinks since it is highly resistant to corrosion from water exposure. It also finds use in other industries, such as medical instrumentation, architectural trim components, and electronics.
Stainless Steel 317L Sheet Grades and Specification
- Sheet Standards: ASTM A240 / ASME SA240
- Sheet Dimensions: ASTM, ASME, and API
- Material: Stainless Steel
- Sheets Width: 160 – 1.500,00 mm
- Sheets Thickness: 0.2 – 6.0 mm
- Sheets Length: 100 to 6.000,00 mm
- Sheets Tolerance: acc. EN ISO 9445:2006 other on request
- Surface finishes: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, perforated, embossed, hairline, sand blast, Brush, etching, Hot rolled Sheet (HR), Cold rolled Sheet (CR), SATIN (Met with Plastic Coated) etc
- Hardness: Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
- Types: Sheets, Perforated Sheet
Equivalent Material of Stainless Steel 317L Sheets
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
Specialized in Stainless Steel 317L Sheets
- Stainless Steel 317L Shim Sheets
- Austenitic Stainless Steel 317L Sheets
- Stainless Steel 317L Industrial Sheets
- SS 317L 2D Finish Sheets Supplier
- SS 317L Sheets at Best Price List In India
- SS 317L 2B Finish Sheets in Mumbai
- 317L SS #4 Polish Finish Sheets
- Stainless Steel 317L Sheets Stocks
- 317L Stainless Steel Hot Rolled Sheets
- Stainless Steel 317L BA Finish Sheet in India
- AISI 317L Sheets
- Stainless Steel 317L Sheets Stockholder
- 317L Stainless Steel Sheets Manufacturer
- Stainless Steel 317L Perforated Sheets
- #8 Mirror Polish Finish Stainless Steel 317L Sheets
- Stainless Steel 317L Sheets Exporters
- Cut To Size Stainless Steel 317L Sheet
- 317L SS Both Side Polished Sheet
- Stainless 317L Sheets Wholesale in Mumbai
- SUS 317L Sheets
- ASME SA240 TP317L Stainless Steel Sheets
- Stainless Steel 317L Sheets Supplier in India
- Stainless Steel 317L Cold Rolled Sheets
- Stainless Steel 1.4438 Sheets
- 317L Stainless Steel Sheets Stockist In Mumbai
- Stainless Steel 317L Sheets Supplier in India
- ASTM A240 TP317L SS Sheets
- Stainless Steel UNS S31703 Sheets
Chemical Properties Of 317L Stainless Steel Sheet
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.89 min |
SS 317L Sheets Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
ASME SA240 Stainless Steel 317L Sheet Sizes
| SS 317L Sheet Weight per Unit Area | Estimated Weight per Sheet |
|---|---|
| 0.630 lbs/ft²3.07566 kg/m² | 15.12 lbs6.84936 kg |
| 0.630 lbs/ft²3.07566 kg/m² | 18.90 lbs8.5617 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 18.15 lbs8.22195 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 22.68 lbs10.27404 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 24.19 lbs10.95807 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 30.24 lbs13.69872 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 20.16 lbs9.13248 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 25.20 lbs11.4156 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 24.19 lbs10.95807 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 30.24 lbs13.69872 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 36.29 lbs16.43937 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 32.26 lbs14.61378 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 40.32 lbs18.26496 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 48.39 lbs21.92067 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 25.20 lbs11.4156 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 31.50 lbs14.2695 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 30.24 lbs13.69872 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 37.80 lbs17.1234 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 45.37 lbs20.55261 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 40.32 lbs18.26496 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 50.41 lbs22.83573 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 60.49 lbs27.40197 kg |
| 1.512 lbs/ft²7.381584 kg/m² | 30.24 lbs13.69872 kg |
| 1.512 lbs/ft²7.381584 kg/m² | 37.80 lbs17.1234 kg |
| 1.512 lbs/ft²7.381584 kg/m² | 36.29 lbs16.43937 kg |
317L Stainless Steel Sheet Thickness & Weight
| Thickness | Thickness | Size Chart | SS 317L Sheet Unit weight | SS 317L Sheet Approx Weight | ||
|---|---|---|---|---|---|---|
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
Stainless Steel 317L Sheet Dimensions
| Surface finish | Thickness (mm) | Width (max mm) |
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | 1524 |
| 2H – Work hardened | 0.4–6.35 | 1524 |
| Polished, brushed | 0.5–4.0 | 1524 |
| Surface finish | Gauge (in) | Width (max in) |
| 2B – Cold rolled, heat treated, pickled, skin passed | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled | 12–24 | 60 |
| Polished (not brushed) | 11–24 | 60 |
Polished and Plain 317L Stainless Steel Sheet
huge stock of polished ss 317L sheets, finishes include Natural, Bright, Brushed, Dull Polished, Mirror and Embossed Rigidised
| PRODUCT | FINISH | THICKNESS MM | MAX SHEET SIZE MM |
|---|---|---|---|
| Grade 317L | Plain 2B | 0.9 | 2000 x 1000 |
| Bright | 0.9 | 2000 x 1000 | |
| Brushed Finish | 0.9, 1.2 | 2000 x 1000, 2500 x 1250 | |
| Rimex Super Mirror | 0.8, 1.2 | 2400 x 1200, 2500 x 1250 | |
| Embossed | 0.8, 1.0 | 2500 x 1250 |
Perforated Stainless Steel Sheet 317L
We now offer circle cutting in Stainless Steel Grade 317L perforated sheets up to 1000mm diameter.
| Hole Dia mm | Hole Centres mm | O/A | Finish | Tck mm | Full Sheet Size mm |
|---|---|---|---|---|---|
| 0.75 | 1.5 | 23% | 2B | 0.6 | 2000 x 1000 |
| 1 | 2 | 23% | 2B | 1.0 | 2000 x 1000 |
| 1.5 | 2.6 | 30% | 2B | 1.0 | 2000 x 1000 |
| 2 | 3.5 | 30% | 2B | 1.0 | 2000 x 1000 |
| 2 | 3.5 | 30% | 2B | 1.0 | 2000 x 1000 |
| 3 | 5 | 33% | 2B | 1.0 | 2000 x 1000 |
| 4 | 5.6 | 46% | 2B | 1.0 | 2000 x 1000 |
| 5 | 8 | 35% | 2B | 1.0 | 2000 x 1000 |
| 6 | 8 | 51% | 2B | 1.0 | 2000 x 1000 |
| 8 | 10 | 58% | 2B | 1,0 | 2000 x 1000 |
317L Stainless Steel Sheet Price List
- grade 317l hot rolled and cold rolled steel sheet
us $900-1600 / ton - 317l 2b finish stainless steel sheet price
us $1000-2000 / ton - the most popular stainless steel sheet 317l / sus 317l 2b manufacturer
us $100-1550 / ton - no.1 2b sheet and 2b finish 317l stainless steel Sheet price
us $15-56 / piece - cold rolled / hot rolled 317l stainless steel sheet
us $500-1600 / ton - cheap price no.1 2b surface stainless steel sheet 317l
us $300-1500 / ton - a240 tp317l stainless steel sheet – no.8 mirror polish
us $125-1200 / ton - 317l 2b surface stainless steel metal sheet
us $1200-2300 / ton - mirror / polish / brush finished 317l stainless steel sheet
us $400-1700 / ton - top quality 317l stainless steel sheet with factory price
us $1100-2100 / ton
Stainless Steel 317L Sheet | Supplier of Stainless Steel 317L Sheet | Stainless Steel 317L Sheet Suppliers | Stainless Steel 317L Sheet Stockists | Stainless Steel 317L Sheet Exporters | Stainless Steel 317L Sheet Manufacturers | Stainless Steel 317L Sheet Latest Price
Stainless Steel 317L Sheet Value Added Services / Processing
- Cladding
- Heat Treatment
- Annealed
- Pickling, Polish
- Rolling
- Cutting
- Bending
- Forging
- Minor Fabrication etc.
- Drilling
- Milling
- Punching
- Forming
- Hot Forming
- Welding
- Shearing
- Grinding
- Testing
