EN 1.4501 Plates, ASTM A240 F55 Plate, Super Duplex Steel F55 Plates, 1.4501 Plates, Super Duplex Steel S32760 Plates, UNS S32760 Plates, Super Duplex Stainless Steel F55 Plate Stockist, Super Duplex S32760 Hot Rolled Plates, Super Duplex Steel S32760 F55 Plates Supplier in Mumbai, India.
Super Duplex UNS S32760 Plates are designed for extremely challenging environments, offering superior performance in corrosive and high-temperature applications ideal for offshore and seawater operations.
ASME SA240 S32760 Super Duplex Steel Plate, SDSS S32760 CR Plates, SDSS S32760 Plate, Super Duplex Stainless Steel S32760 Plate Suppliers, Super Duplex Steel F55 Plate Manufacturers, Super Duplex S32760 Chequered Plates, Super Duplex Steel S32760 Plates Stockist in India.
Offering excellent mechanical properties, including a minimum yield strength of 650 MPa (92ksi), these plates provide superior resistance to chloride pitting corrosion and crevice corrosion. With higher chromium levels than standard duplex grades, Super Duplex EN 1.4501 Plates offer good weldability with low carbon content while providing exceptional service life in even the most demanding conditions. The combination of chrome, molybdenum, nitrogen, and copper enhances their ability to resist chloride pitting and crevice corrosion, making them ideal for use in extreme temperature and pressure environments such as those found in the oil and gas industry. These plates are also highly resistant to stress-corrosion cracking, making them suitable for a range of structural applications including storage tanks and heat exchangers. Finally, Super Duplex UNS S32760 Plates are available in numerous thicknesses and dimensions to meet customer requirements.
Super Duplex F55 Plates offer exceptional performance with increased strength, wear resistance, and toughness compared to conventional stainless steel grades. This unique combination of properties makes these plates well-suited for a variety of applications, including bellows, valves, pumps, and heat exchangers. Additionally, these plates are easy to form and machine and offer excellent weldability with low carbon content. With superior corrosion resistance and excellent temperature capabilities, Super Duplex UNS S32760 Plates provide a cost-effective solution for the most demanding projects.
At Palgotta Metal Pvt Ltd, we carry a wide selection of EN 1.4501 / Super Duplex UNS S32760 / F55 Plates in stock so you have the exact product you need for your job. Our team is dedicated to providing quality products at competitive prices with fast shipping times – all backed by our commitment to 100% customer satisfaction.
Super Duplex S32760 Plate Grades and Specification
- Plate Standards: ASTM A240 / ASME SA240 / NACE MR-0175
- Plate Material: Super Duplex Steel
- Plate Size : 1000 x 2000 mm, 1220 x 2440 mm, 1500 x 3000 mm, 2000 x 2000 mm, 2000 x 4000 mm
Cold rolled Super Duplex Plate – 0.5-6.4 mm
Hot rolled Super Duplex Plate – 3.0–10.0 mm - Plates Technique: Hot Rolled and Cold Rolled. Super Duplex Steel Plate
- Plates Width: 10-2500mm
- Plates Thickness: 0.1 to 100 mm Thk
- Plates Length: 2m, 2.44m, 3m, or as required
- Super Duplex Plate Finish: 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled Super Duplex Stainless Steel Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc.
- Plate Hardness: Soft, Hard, Half Hard, Quarter Hard, Spring Hard
- Types: Plates, Chequered Plate
Equivalent Material of Super Duplex F55 Plates
| STANDARD | WERKSTOFF NR. | UNS / Grade |
| ASTM A240 / ASME SA240 | 1.4501 | S32760 (F55) |
Specialized in Super Duplex Stainless Steel F55 Plates
- Super Duplex Steel F55 #4 Polish Finish Plates
- SDSS S32760 HR Plates
- Super Duplex F55 Plates Wholesale in Mumbai
- EN 1.4501 Plates Stocks
- SDSS S32760 Plates Manufacturer
- Super Duplex S32760 2B Finish Plates in Mumbai
- Super Duplex S32760 F55 Chequered Plates
- Super Duplex Steel S32760 BA Finish Plate in India
- S32760 Super Duplex Steel Plates
- Super Duplex Steel S32760 Industrial Plates
- Super Duplex Steel F55 Plates Thickness
- S32760 Super Duplex Plates Stockholder
- F55 Super Duplex Steel 2D Finish Plates Supplier
- Super Duplex 1.4501 Plates Stockist In Mumbai
- #8 Mirror Polish Finish SDSS S32760 Plates
- Super Duplex S32760 Both Side Polished Plate
- Cut To Size Super Duplex Stainless Steel S32760 Plate
- Super Duplex F55 Plates Supplier in India
- ASTM A240 Super Duplex F55 Plates
- SDSS EN 1.4501 Plates Supplier in India
- Super Duplex UNS S32760 Plates
- Super Duplex Steel F55 Plates at Best Price List In India
- Super Duplex S32760 Plates
- ASME SA240 Super Duplex Steel S32760 Plates
- Super Duplex Stainless Steel S32760 Plates
- Super Duplex S32760 Plates Exporters
Chemical Properties Of Super Duplex Steel EN 1.4501 Plate
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
Super Duplex Stainless Steel F55 Plates Mechanical Properties
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
ASTM A240 Super Duplex Steel S32760 Plate Sizes Chart
| Thickness | Thickness | Size Range | Surface Area per Unit weight | Approx Weight per Plate | ||
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
|---|---|---|---|---|---|---|
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
SDSS S32760 Plate Weight Chart
| Weight per | Size | Size | Weight per | ||||
| Plates (Kg) | (mm) | (mm) | Plates (Kg) | ||||
| 12.8 | 2500 x | 1250 x | 0.5 | 2000 x | 1000 x | 1.5 | 24.6 |
| 8.2 | 2000 x | 1000 x | 0.5 | 3000 x | 1500 x | 1.2 | 44.2 |
| 17.9 | 2500 x | 1250 x | 0.7 | 3000 x | 1500 x | 1.5 | 55.3 |
| 13.1 | 2000 x | 1000 x | 0.8 | 2000 x | 1000 x | 2.0 | 32.7 |
| 11.5 | 2000 x | 1000 x | 0.7 | 2500 x | 1250 x | 1.5 | 38.4 |
| 14.7 | 2000 x | 1000 x | 0.9 | 3000 x | 1500 x | 2.0 | 73.7 |
| 20.5 | 2500 x | 1250 x | 0.8 | 2500 x | 1250 x | 2.0 | 51.2 |
| 33.2 | 3000 x | 1500 x | 0.9 | 2500 x | 1250 x | 2.5 | 63.9 |
| 36.8 | 3000 x | 1500 x | 1.0 | 2500 x | 1250 x | 3.0 | 77.5 |
| 23.0 | 2500 x | 1250 x | 0.9 | 2000 x | 1000 x | 2.5 | 40.9 |
| 25.6 | 2500 x | 1250 x | 1.0 | 2000 x | 1000 x | 3.0 | 49.6 |
| 16.4 | 2000 x | 1000 x | 1.0 | 3000 x | 1500 x | 2.5 | 92.1 |
| 19.6 | 2000 x | 1000 x | 1.2 | 3000 x | 1500 x | 3.0 | 112.0 |
| 30.7 | 2500 x | 1250 x | 1.2 | – | – | – | – |
Super Duplex Steel S32760 Plate Dimensions
| Surface finish | Thickness (mm) | Width (max mm) |
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | 1524 |
| 2H – Work hardened | 0.4–6.35 | 1524 |
| Polished, brushed | 0.5–4.0 | 1524 |
| Surface finish | Gauge (in) | Width (max in) |
| 2B – Cold rolled, heat treated, pickled, skin passed | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled | 12–24 | 60 |
| Polished (not brushed) | 11–24 | 60 |
Super Duplex UNS S32760 F55 Plates Price List
- no.1 2b plate and 2b finish s32760 super duplex steel plate price per kg
FOB Price US $2,400.00-$3,520.00 / Ton - grade f55 2b surface super duplex steel metal plate
FOB Price US $1,200.00-$1,500.00 / Ton - super duplex steel en 1.4501 hot rolled and cold rolled plate
FOB Price US $2,460.00-$5,330.00 / Ton - 2b finish super duplex stainless steel f55 plate price
FOB Price US $2.40-$8.40 / Kilogram - mirror / polish / brush finished super duplex steel S32760 plate
FOB Price US $3.25-$2.00 / Kilogram - the most popular super duplex steel plate s32760 2b manufacturer
FOB Price US $2,400.00-$5,320.00 / Ton - cheap price no.1 2b surface super duplex steel plate uns s32760
FOB Price US $2.50-$4.00 / Kilogram - astm a240 super duplex stainless steel f55 plate – no.8 mirror polish
FOB Price US $3,300.00-$2,300.00 / Ton - top quality super duplex steel en 1.4501 plate with factory price
FOB Price US $3,100.00-$2,300.00 / Ton - cold rolled / hot rolled super duplex stainless steel S32760 plate
FOB Price US $3,300.00-$1,350.00 / Ton
Super Duplex Stainless Steel F55 Plate Latest Price | Super Duplex Steel EN 1.4501 Plate | Supplier of Super Duplex UNS S32760 Plate | Super Duplex S32760 Plate Stockists | Super Duplex Steel S32760 Plate Manufacturers | SDSS S32760 F55 Plate Suppliers | Super Duplex 1.4501 Plate Exporters.
Super Duplex UNS S32760 Plate Value Added Services / Processing
- Cladding
- Heat Treatment
- Annealed
- Pickling, Polish
- Rolling
- Cutting
- Bending
- Forging
- Minor Fabrication etc.
- Drilling
- Milling
- Punching
- Forming
- Hot Forming
- Welding
- Shearing
- Grinding
- Testing
