Alloy LDX 2101 Plate, Lean Duplex 2101 Plate Stockist, EN 1.4162 Plates, Duplex LDX 2101 Plate Manufacturers, UNS S32101 Plates, Lean Duplex Stainless Steel S32101 Plates Supplier in Ahmedabad, India.
Our Lean Duplex UNS S32101 Plates are the perfect solution for applications that require high strength and excellent corrosion resistance. With a balanced composition of austenitic and ferritic steels, these plates offer good weldability with improved mechanical properties, greater flexibility and increased oxidation resistance compared to traditional stainless steel plates. The low alloying content also makes our Lean Duplex UNS S32101 Plates more economical than other commonly used stainless steel grades. Our plates are available in thicknesses ranging from 3mm-200mm, making them suitable for any application you may have.
Lean Duplex S32101 Plate Suppliers, Stock of ASTM A240 2101 Lean Duplex Steel Plate, LDX 2101 Duplex Steel Chequered Plates, LDX 2101 Stainless Steel Plate Price, ASME SA240 UNS S32101 Plate, LDX 2101® Plates in India.
These EN 1.4162 / Lean Duplex UNS S32101 / LDX 2101 plates have superior pitting resistance when compared to standard stainless steel grades such as 304L/316L and can be used in a wide range of industries including petrochemical and aerospace. Our EN 1.4162 / Lean Duplex UNS S32101 / LDX 2101 plates provide excellent resistance to stress corrosion cracking, making them ideal for use in demanding environments such as high-pressure, high-temperature oil and gas pipelines. In addition, these plates are non-magnetic and have good weldability characteristics, so they can be easily joined together.
At Palgotta Metal Pvt Ltd, our Lean Duplex UNS S32101 Plates are supplied with quality assurance testing to ensure they meet the highest standards. We offer both standard-size sheets and cut-to-size pieces that are designed to meet your exact needs. With our superior customer service and competitive prices, we guarantee you’ll be happy with your purchase.
Lean Duplex Steel S32101 Plate Grades and Specification
- Standards: ASTM A240 / ASME SA240 / NACE MR-0175
- Material: Lean Duplex Steel
- EN 1.4162 Plate Size : 1000 x 2000 mm, 1220 x 2440 mm, 1500 x 3000 mm, 2000 x 2000 mm, 2000 x 4000 mm
Cold rolled Lean Duplex Plate – 0.5-6.4 mm
Hot rolled Lean Duplex Plate – 3.0–10.0 mm - Plates Technique: Hot Rolled and Cold Rolled. Lean Duplex Steel Plate
- LDX 2101 Plates Width: 10-2500mm
- 2101 LDX Plates Thickness: 3/16″ to 2.0″ Thk
- Lean Duplex UNS S32101 Plates Length: 2m, 2.44m, 3m, or as required
- S32101 Lean Duplex Plate Finish: 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled Lean Duplex Stainless Steel Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc.
- Hardness: Soft, Hard, Half Hard, Quarter Hard, Spring Hard
- Types: Plates, Chequered Plate
Features and Benefits
- High corrosion resistance in harsh environments
- Optimized strength-to-weight ratio for reduced material costs and increased efficiency
- Cost-effective solution without compromising on performance
- Good formability and weldability for easy fabrication and installation
- Resistance to pitting and crevice corrosion for long-term reliability
Are LDX 2101 Plates corrosion-resistant?
LDX 2101 Plates are highly corrosion-resistant, offering superior resistance to localized and uniform corrosion due to their high chromium, nitrogen, and molybdenum content. The duplex microstructure of LDX 2101 contributes to its exceptional strength and resistance to chloride stress-corrosion cracking, making it suitable for a wide range of applications. The corrosion resistance of LDX 2101 Plates is generally good, surpassing 304L stainless steel and comparable to 316L stainless steel, ensuring reliability in various environments and industries
What are the MOQ and order size flexibility for LDX 2101 Plates?
The minimum order quantity for LDX 2101 plates is typically 100 KG. However, we understand that different projects have unique requirements, so we are flexible with order sizes to accommodate your needs. Whether you need a small batch or a larger quantity, we can adjust it to suit your project.
Is custom thickness available for Duplex UNS S32101 Plates?
Yes, we offer custom thickness options for our duplex S32101 plates. If you need a specific thickness that is not listed in our standard sizes, we can accommodate your requirements. Provide us with your desired specifications, and our team will work with you to deliver plates that meet your exact needs.
How can I order LDX 2101 plates?
To purchase our LDX 2101 plates, contact our sales team via phone or email, or you can fill out our online quote form. Provide your specific requirements, and we’ll guide you through the order process. Our team is here to assist you every step of the way to ensure a smooth and satisfying buying experience.
Do you provide discounts for bulk purchases of LDX 2101 Plates?
Yes, we offer discounts for bulk purchases of LDX 2101 plates. The more you order, the better the pricing we can provide. We offer competitive rates for large orders to help you save on costs. Contact us for more details on our volume pricing.
What are the return and warranty policies in place in case of any issues with the LDX 2101 Plates?
At Palgotta Metal Pvt Ltd, we want you to be happy with your purchase. If there’s any problem with our LDX 2101 plates, just let us know within a week. We’ll quickly replace them or give you a refund. Your satisfaction is our top priority, and we’re here to help with any issues.
Are LDX 2101 Plates certified for compliance with industry standards?
Our LDX 2101 plates are certified to meet ASTM and EN standards, ensuring high quality and safety. You can trust that our plates are reliable and meet industry benchmarks.
Lean Duplex S32101 Plates Price List
- cold rolled / hot rolled alloy ldx 2101 plate
FOB Price US $2,100.00-$2,888.00 / Ton - no.1 2b plate and 2b finish ldx2101 stainless steel plate price per kg
FOB Price US $3,500.00-$2,850.00 / Ton - the most popular lean duplex steel plate 2101 2b manufacturer
FOB Price US $4,200.00-$3,420.00 / Ton - grade s32101 2b surface lean duplex steel metal plate
FOB Price US $1,270.00-$1,500.00 / Ton - mirror / polish / brush finished lean duplex steel s32101 plate
FOB Price US $3.20-$8.00 / Kilogram - astm a240 stainless steel LDX 2101 plate – no.8 mirror polish
FOB Price US $2,160.00-$3,547.00 / Ton - 2b finish lean duplex stainless steel s32101 plate price
FOB Price US $2.15-$5.70 / Kilogram - lean duplex stainless steel en 1.4162 hot rolled and cold rolled plate
FOB Price US $2,250.00-$2,500.00 / Ton - top quality lean duplex steel en 1.4162 plate with factory price
FOB Price US $1,230.00-$3,600.00 / Ton - cheap price no.1 2b surface lean duplex steel plate uns s32101
FOB Price US $4.12-$4.00 / Kilogram
Equivalent Material of Lean Duplex 2101 Plates
| Grade | Euronorm | Nom. | AISI / UNS |
|---|---|---|---|
| 2101 | 1.4162 | X2CrMnNiN21-5-1 | S32101 (2101) |
Different Types of Lean Duplex Steel UNS S32101 (2101) Plates
Specialized in Lean Duplex Steel S32101 Plates
- Lean Duplex Steel S32101 2B Finish Plates
- Lean Duplex 2101 HR Plates
- Lean Duplex UNS S32101 Chequered Plates
- Lean Duplex UNS S32101 Industrial Plates
- EN 1.4162 Plates
- LDX 2101 Steel Plates
- Alloy LDX 2101® Plates
- Duplex LDX 2101 Plates
- Lean Duplex 1.4162 Plates in India
- Duplex SS LDX 2101 BA Finish Plate in India
- LDX2101 Stainless Steel 2D Finish Plates
- Alloy LDX 2101 #4 Polish Finish Plates
- Lean Duplex LDX 2101® Plates
- Cut To Size Lean Duplex Stainless Steel 2101 Plate
- Lean Duplex LDX 2101 Plates in Mumbai
- ASME SA240 Lean Duplex UNS S32101 Plates
- #8 Mirror Polish Finish Stainless Steel 2101 Plates
- Lean Duplex 2101 Plates
- Lean Duplex Stainless Steel LDX 2101 Plates
- Lean Duplex 2101 Both Side Polished Plate
- Lean Duplex Steel 1.4162 Plates
- Alloy LDX 2101® Cold Rolled Plates
- Lean Duplex 1.4162 Plates in Mumbai
- ASTM A240 Alloy LDX 2101® Plates
- Lean Duplex EN 1.4162 Plates
- Lean Duplex UNS S32101 Plates
Technical Specifications
Chemical Properties Of Lean Duplex Steel EN 1.4162 Plate
21.5% Chromium, 1.5% Nickel, 0.1% Molybdenum, 5% Manganese, 0.22% Nitrogen
| Weight % | C | Si | Mn | S | P | Cr | Ni | Mo | N | Cu |
| Min. | 4,00 | 21,00 | 1,35 | 0,1 | 0,20 | 0,10 | ||||
| Max. | 0,040 | 1,00 | 6,00 | 0,015 | 0,035 | 22,00 | 1,90 | 0,8 | 0,25 | 0,80 |
Duplex Stainless Steel LDX 2101 Plates Mechanical Properties
Yield Strength (min) 450 MPa, Tensile Strength 650-850 MPa, Elongation (min) 25%
| Yield strength Rp0.2, MPa |
Tensile strength Rm, MPa |
Elongation [%] |
Hardness [HB] |
Impact, Charpy-V, -40ºC [J] |
Pre | Surface | |
| PLATE CR (COIL) | ≥ 530 | ≥ 700 | ≥ 30 | ≥ 50 | 26 | 2B/2E | |
| PLATE HR (COIL) | ≥ 450 | ≥ 650 | ≥ 30 | ≤ 290 | ≥ 50 | 26 | 1D |
| PLATE (QUARTO) | ≥ 450 | ≥ 650 | ≥ 30 | ≤ 290 | ≥ 27 | 26 | 1D |
ASTM A240 Lean Duplex Steel S32101 Plate Sizes Chart
| Thickness | Thickness | Size Range | Surface Area per Unit weight | Approx Weight per Plate | ||
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
|---|---|---|---|---|---|---|
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
Stainless Steel LDX 2101 Plate Weight Chart
| Weight per | Size | Size | Weight per | ||||
| Plates (Kg) | (mm) | (mm) | Plates (Kg) | ||||
| 12.8 | 2500 x | 1250 x | 0.5 | 2000 x | 1000 x | 1.5 | 24.6 |
| 8.2 | 2000 x | 1000 x | 0.5 | 3000 x | 1500 x | 1.2 | 44.2 |
| 17.9 | 2500 x | 1250 x | 0.7 | 3000 x | 1500 x | 1.5 | 55.3 |
| 13.1 | 2000 x | 1000 x | 0.8 | 2000 x | 1000 x | 2.0 | 32.7 |
| 11.5 | 2000 x | 1000 x | 0.7 | 2500 x | 1250 x | 1.5 | 38.4 |
| 14.7 | 2000 x | 1000 x | 0.9 | 3000 x | 1500 x | 2.0 | 73.7 |
| 20.5 | 2500 x | 1250 x | 0.8 | 2500 x | 1250 x | 2.0 | 51.2 |
| 33.2 | 3000 x | 1500 x | 0.9 | 2500 x | 1250 x | 2.5 | 63.9 |
| 36.8 | 3000 x | 1500 x | 1.0 | 2500 x | 1250 x | 3.0 | 77.5 |
| 23.0 | 2500 x | 1250 x | 0.9 | 2000 x | 1000 x | 2.5 | 40.9 |
| 25.6 | 2500 x | 1250 x | 1.0 | 2000 x | 1000 x | 3.0 | 49.6 |
| 16.4 | 2000 x | 1000 x | 1.0 | 3000 x | 1500 x | 2.5 | 92.1 |
| 19.6 | 2000 x | 1000 x | 1.2 | 3000 x | 1500 x | 3.0 | 112.0 |
| 30.7 | 2500 x | 1250 x | 1.2 | – | – | – | – |
Lean Duplex 2101 Plate Dimensions
| Surface finish | Thickness (mm) | Width (max mm) |
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | 1524 |
| 2H – Work hardened | 0.4–6.35 | 1524 |
| Polished, brushed | 0.5–4.0 | 1524 |
| Surface finish | Gauge (in) | Width (max in) |
| 2B – Cold rolled, heat treated, pickled, skin passed | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled | 12–24 | 60 |
| Polished (not brushed) | 11–24 | 60 |
EN 1.4162 Plates Applications
Our Lean Duplex EN 1.4162 Plates are suitable for a wide range of applications, including:
- Petrochemical, oil and gas industries, where high corrosion resistance is critical
- Infrastructure and construction projects, such as buildings, bridges, and roads.
- Water treatment and desalination plants, where corrosion resistance and hygiene are essential
- Food processing and pharmaceutical industries, where sanitation and corrosion resistance are critical
- Marine and offshore applications, where exposure to seawater and harsh environments is a concern
Lean Duplex Steel EN 1.4162 Plate | Supplier of Lean Duplex UNS S32101 Plate in India | Stainless Steel LDX 2101® Plate Suppliers | Lean Duplex S32101 Plate Stockists | Lean Duplex 1.4162 Plate Exporters | 2101 Stainless Steel Plate Manufacturers | Lean Duplex Stainless Steel S32101 Plate Latest Price
Lean Duplex UNS S32101 Plate Value Added Services / Processing
- Cladding
- Heat Treatment
- Annealed
- Pickling, Polish
- Rolling
- Cutting
- Bending
- Forging
- Minor Fabrication etc.
- Drilling
- Milling
- Punching
- Forming
- Hot Forming
- Welding
- Shearing
- Grinding
- Testing
